緯綸為您解讀連接器的重要性 WEILLEN Understand the importance of connectors
設想一下如果沒有連接器會是怎樣？這時電路之間要用連續的導體永久性地連接在一起，例如電子裝置要連接在電源上，必須把連接導線兩端，與電子裝置及電源通過某種方法（例如焊接）固定接牢。這樣一來，無論對于生產還是使用，都帶來了諸多不便。
以LED景觀燈為例。從電源到燈座的距離一般都會比較大，如果從電源到燈座都是每根線從頭到尾連接，那將會給施工帶來不必要的麻煩，而且會造成線材浪費。有人會疑問，直接從火線開個缺口，將電線導電的部位接到一起，再纏上幾層絕緣膠不也可以嗎？
不一定非要用連接器。首先，絕緣膠布大多容易老化，存在安全隱患；其次直接用電線搭在一起的接頭機械性能是很差的，線路稍微振動拉伸很容易造成斷路，而且接口接觸不良，容易造成發熱，從而引發火災；況且戶外環境惡劣，防水防鹽防老化等要求都會比較高，絕緣膠遠達不到要求。但是如果在戶外照明中使用高性能防水連接器，不僅簡化了電網的安裝，而且這一切的安全隱患都會降到很低的水平。
.jpg "16085161831605859833(1).jpg")
這個例子簡單的說明了連接器的好處。它使設計和生產過程更方便、更靈活，更加安全，也降低了生產和維護成本。 連接器的出現改善生產過程 連接器簡化電子產品的裝配過程，也簡化了批量生產過程 易于維修 如果某電子元部件失效，裝有連接器時可以快速更換失效元部件，便于升級 隨著技術進步，裝有連接器時可以更新元部件，用新的、更完善的元部件代替舊的 提高設計的靈活性使用連接器使工程師們在設計和集成新產品時，以及用元部件組成系統時，有更大的靈活性。
尤其是對工業連接器來說，有時候用在需要插拔的惡劣環境中，靈活與安全就顯得更為重要。這時候帶按扣的簡易插拔連接器會是一個明智的選擇。
Imagine what it would be like without connectors.
At this time, the circuit must be permanently connected with continuous conductors. For example, to connect the electronic device to the power supply, the two ends of the connecting wire must be firmly connected with the electronic device and the power supply through some method (such as welding).
So, no matter to produce or use, brought a lot of inconvenience.
Take the LED landscape lamp as an example.
The distance from the power supply to the lamp holder is usually large. If every wire from the power supply to the lamp holder is connected from the beginning to the end, it will bring unnecessary trouble to the construction and will cause wire waste.
Some people can doubt, open a gap from firewire directly, the place that electric wire conducts is joined together, wrap on a few insulation glue again not also ok?
You don't have to use connectors.
First of all, most of the insulation tape is easy to aging, there are safety hazards;
Secondly, the mechanical properties of the joints directly put together by wires are very poor. It is easy to break the circuit if the wires are slightly vibrated and stretched. In addition, poor interface contact is easy to cause heat, thus causing fire.
Besides outdoor environment is abominable, waterproof prevent salt to prevent aging to wait for a requirement to be met quite tall, insulation glue is far short of a requirement.
However, the use of high-performance waterproof connectors in outdoor lighting not only simplifies the installation of the power grid, but also reduces all the potential safety hazards to a very low level.
This example simply illustrates the benefits of connectors.
It makes the design and production process more convenient, more flexible, more secure, and reduces production and maintenance costs.
.jpg "16085162171605859833(1).jpg")
Connector of improving production process simplified electronic product assembly process, also simplified the production process is easy to repair if some electronic components failure, can quickly change the failure components when equipped with a connector, easy to upgrade with technical progress, equipped with a connector can be updated when the components, with a new, better instead of the old improve the design of the components, the flexibility of using connectors to the engineers in the design and integration of new products, and use the components of system, the more flexibility.
Especially for industrial connectors, it is important to be flexible and safe when used in harsh environments where plugging is required.
A simple plug-in connector with a buckle is a wise choice at this point.
